Switch Unit Exploded View IR 112

Type: 104573
Ships from: FOB Brampton Canada
U/M: Each
Stock: On Order
CM: 2111

* Switch Unit Exploded View IR 112:

CM Machine Services Ltd. Product Information

To make Purchase Call 905-793-3994 or Email sales@cmmachineservices.net Prices are subject to change without notice.

Switch Unit Exploded View IR 112

Type: 104573
Brand: 1037
Location: FOB Brampton Canada
U/M: Each
Stock: On Order
CM Product Code: 2111

* Switch Unit Exploded View IR 112:
--F250270 Plate / Sheet
--F240041 Threaded rod
--F250280 Shaft
--F245844 Cylinder head screw
--F20570 Washer
--F20203 Hexagonal nut
--F444874 Mini hub drive

Switch Unit Exploded View IR 112

Pos. No.	Part No.	Description	Add. Info	Required
1	F250270	Plate / Sheet	121 x 80 x 4	1
2	F240041	Threaded rod	Ø 10 x 217	1
3	F250280	Shaft	Ø 20 x 242	1
4	F245844	Cylinder head screw	DIN912 M 4 x 16	2
5	F20570	Washer	DIN125 A 4,3	2
6	F20203	Hexagonal nut	DIN934 M 6	1
7	F444874	Mini hub drive	MHG 100/50	1
