Switch Unit Exploded View Ruhle SR2 No. 74 and Higher

Type: 103724
Ships from: FOB Brampton Canada
U/M: Each
Stock: On Order
CM: 703

Note: Shipping to be Determined.

* Switch Unit Exploded View:

CM Machine Services Ltd. Product Information

To make Purchase Call 905-793-3994 or Email sales@cmmachineservices.net Prices are subject to change without notice.

Switch Unit Exploded View Ruhle SR2 No. 74 and Higher

Type: 103724
Location: FOB Brampton Canada
U/M: Each
Stock: On Order
CM Product Code: 703

Note: Shipping to be Determined.

* Switch Unit Exploded View:
--F241301 Bracket
--F240666 Plate / Sheet
--F240665 Plate / Sheet
--F240977 Cylinder head screw
--F28941 Switch cable-breakage safety
--F29058 Cable gland

Switch Unit Exploded View for Ruhle SR2 Meat Dicer

Pos No.	Part No.	Description	Add Info	Required
1	F241301	Bracket	130 x 122,5 x 50 x 2,5	1
2	F240666	Plate / Sheet	80 x 40 x 3	1
3	F240665	Plate / Sheet	93 x 20 x 10	1
4	F240977	Cylinder head screw	DIN84 M 5 x 35	4
5	F28941	Switch cable-breakage safety	ENK-SU1Z AHS	1
6	F29058	Cable gland	M 20 x 1.5	1

CM Machine Services Ltd. | 55 Stafford Drive Unit "I" | Brampton, On L6W 1L3

PH: 905-793-3994 | Contact: sales@cmmachineservices.net

Description

Switch Unit Exploded View for Ruhle SR2 Meat Dicer

Pos No.	Part No.	Description	Add Info	Required
1	F241301	Bracket	130 x 122,5 x 50 x 2,5	1
2	F240666	Plate / Sheet	80 x 40 x 3	1
3	F240665	Plate / Sheet	93 x 20 x 10	1
4	F240977	Cylinder head screw	DIN84 M 5 x 35	4
5	F28941	Switch cable-breakage safety	ENK-SU1Z AHS	1
6	F29058	Cable gland	M 20 x 1.5	1
