Switch Box Assembly Ruhle IR112 Meat Injector F456962et

Type: F456962et
Ships from: FOB Brampton Canada
U/M: Each
Stock: On Order
CM: 2228

* Switch Box Assembly 1 IR 112:

CM Machine Services Ltd. Product Information

To make Purchase Call 905-793-3994 or Email sales@cmmachineservices.net Prices are subject to change without notice.

Switch Box Assembly Ruhle IR112 Meat Injector F456962et

Type: F456962et
Location: FOB Brampton Canada
U/M: Each
Stock: On Order
CM Product Code: 2228

* Switch Box Assembly 1 IR 112:
--F459437 Switch box
--F20259 Hexagonal nut
--F23418 Disc
--F21260 Spring lock washer
--F21260 Spring lock washer
--F28732 lock washer
--F20258 Washer
--F24031 Spring lock washer
--F20203 Hexagonal nut
--F250691 Lid
--F20664 Seal
--F21045 Washer
--F22174 Cylinder head screw
--F25910 Hexagonal bolt
--F26336 Lock washer
--F21028 Hexagonal nut
--F22888 Washer
--F251999 Cable gland
--F252001 Cable sleeve
--F252000 Cable sleeve
--F26115 Blank Plug
--F25780 Hexagonal nut
--F148541 Sticker
--F10131 Sticker
--104916 Cable sleeve
--106489 Computer box
--106635 ground wire

Switch Box Assembly Ruhle IR112 Meat Injector F456962et

Pos No.	Part No.	Description	Add Info	Required
1	F459437	Switch box	IR 112 / MKR 300/600	1
2	F20259	Hexagonal nut	DIN934 M 8	6
3	F23418	Disc	Ø 8,5 x Ø 35 x 3	4
4	F21260	Spring lock washer	DIN127 B 8	6
5	F28732	lock washer	DIN6797-A ø 6,4	3
6	F20258	Washer	DIN125 A 6,4	3
7	F24031	Spring lock washer	DIN127 B 6	3
8	F20203	Hexagonal nut	DIN934 M 6	3
9	F250691	Lid	410 x 155 x 18 x 2	1
10	F20664	Seal	18 x 3	1
11	F21045	Washer	DIN125 A 5,3	9
12	F20260	Spring lock washer	DIN127 B 5	7
13	F22174	Cylinder head screw	DIN912 M 5 x 12	6
14	F25910	Hexagonal bolt	DIN933 M 5 x 25	1
15	F26336	Lock washer	DIN6797-A Ø 5,3	1
16	F21028	Hexagonal nut	DIN934 M 5	2
17	F22888	Washer	DIN125 A 8,4	2
18	F251999	Cable gland	KVT63-4, grey	1
19	F252001	Cable sleeve	KT 4, grey	1
20	F252000	Cable sleeve	KT 6, grey	2
21	F26115	Blank Plug	M 20 x 1,5	2
22	F25780	Hexagonal nut	M 20 x 1,5	2
23	F148541	Sticker	BMK02	3
24	F10131	Sticker	flash	1
25	104916	Cable sleeve	KT 8, grey	1
26	106489	Computer box	Kuhnke Ventura 800	1
27	106635	ground wire	lid - SK 3 (PC-box)	1

CM Machine Services Ltd. | 55 Stafford Drive Unit "I" | Brampton, On L6W 1L3

PH: 905-793-3994 | Contact: sales@cmmachineservices.net
