Switch Box Assembly Ruhle IR112 Injector

Type: F450677
Ships from: FOB Brampton Canada
U/M: Each
Stock: On Order
CM: 2225

* Switch Box Assembly IR 112:

CM Machine Services Ltd. Product Information

To make Purchase Call 905-793-3994 or Email sales@cmmachineservices.net Prices are subject to change without notice.

Switch Box Assembly Ruhle IR112 Injector

Type: F450677
Location: FOB Brampton Canada
U/M: Each
Stock: On Order
CM Product Code: 2225

* Switch Box Assembly IR 112:
--100401 Switch box
--102698 Mounting plate
--F22888 Washer
--F20259 Hexagonal nut
--F20258 Washer
--F24031 Spring lock washer
--F20203 Hexagonal nut
--F256697 Bracket
--F240727 Bracket
--102738 Plate / Sheet
--F21035 Disc
--F22449 Hexagonal bolt
--F23418 Disc
--F20664 Seal
--F250688 Lid
--F21045 Washer
--F20260 Spring lock washer
--F20260 Spring lock washer
--F22174 Cylinder head screw
--F148541 Sticker
--F10131 Sticker
--F26955 Relay 1 change-over
--F20920 Relay 2 change-over
--F29058 Cable gland
--F25780 Hexagonal nut
--F29057 Cable gland
--F29060 Hexagonal nut
--F26132 Sealing ring
--F25978 Cable gland
--F24720 Hexagonal nut
--F240172 Sealing ring
--101964 feed cable
--F20698 Cable
--F20698 Cable
--F20698 Cable
--F20698 Cable
--F20698 Cable
--F25303 Cable
--F25303 Cable
--F25303 Cable
--F23066 Cable
--F23309 Socket
--F23343 Cable
--F23343 Cable
--F23343 Cable
--F23343 Cable
--F23343 Cable
--F23343 Cable
--F23343 Cable
--F20696 Cable
--F29221 Resistance thermometer IR/LR
--F23523 Cable
--F23523 Cable
--F23523 Cable
--F23523 Cable
--F28388 Contact element 1Ö
--F20700 Cable
--F28100 Cable
--F28100 Cable
--F25303 Cable

Switch Box Assembly Ruhle IR112 Injector

Pos No.	Part No.	Description	Add Info	Required
1	100401	Switch box	IR 112	1
2	102698	Mounting plate	IR 112	1
3	F22888	Washer	DIN125 A 8,4	4
4	F21260	Spring lock washer	DIN127 B 8	6
5	F20259	Hexagonal nut	DIN934 M 8	4
6	F20258	Washer	DIN125 A 6,4	6
7	F24031	Spring lock washer	DIN127 B 6	10
8	F20203	Hexagonal nut	DIN934 M 6	10
9	F256697	Bracket	38 x 25 x 160 x 2	1
10	F240727	Bracket	104 x 104 x 30	1
11	102738	Plate / Sheet	100 x 210 x 3	1
12	F21035	Disc	Ø 6,5 x Ø 20 x 2	4
13	F22449	Hexagonal bolt	DIN933 M 8 x 20	2
14	F23418	Disc	Ø 8,5 x Ø 35 x 3	2
15	F20664	Seal	18 x 3	1350 mm
16	F250688	Lid	744 x 580 x 18 x 2	1
17	F21045	Washer	DIN125 A 5,3	18
18	F20260	Spring lock washer	DIN127 B 5	18
19	F22174	Cylinder head screw	DIN912 M 5 x 12	18
20	F148541	Sticker	BMK02	6
21	F10131	Sticker	flash	1
22	F26955	Relay 1 change-over	40.51	2
23	F20920	Relay 2 change-over	44.52	1
24	F29058	Cable gland	M 20 x 1.5	10
25	F25780	Hexagonal nut	M 20 x 1,5	10
26	F29057	Cable gland	M 25 x 1.5	9
27	F29060	Hexagonal nut	M 25 x 1,5	9
28	F26132	Sealing ring	M 25 / 4 x 6 mm	5
29	F25978	Cable gland	M 32 x 1.5	7
30	F24720	Hexagonal nut	M 32 x 1,5	7
31	F240172	Sealing ring	M 32 / 4 x 7 mm	7
32	101964	feed cable	IR 112	1
33	F20698	Cable	ÖZ-J 4 x 1.5 mm²	1700 mm
34	F20698	Cable	ÖZ-J 4 x 1.5 mm²	3800 mm
35	F20698	Cable	ÖZ-J 4 x 1.5 mm²	2950 mm
36	F20698	Cable	ÖZ-J 4 x 1.5 mm²	2500 mm
37	F20698	Cable	ÖZ-J 4 x 1.5 mm²	7700 mm
38	F25303	Cable	ÖZ-J 7x1.0 mm²	4100 mm
39	F25303	Cable	ÖZ-J 7x1.0 mm²	4050 mm
40	F25303	Cable	ÖZ-J 7x1.0 mm²	4050 mm
41	F25303	Cable	ÖZ-J 7x1.0 mm²	70 mm
42	F23066	Cable	ÖZ-J 4 x 1.0 mm²	3700 mm
43	F23309	Socket	GDM 3011	4
44	F23343	Cable	ÖZ-J 3 x 1.0 mm²	3250 mm
45	F23343	Cable	ÖZ-J 3 x 1.0 mm²	3350 mm
46	F23343	Cable	ÖZ-J 3 x 1.0 mm²	2750 mm
47	F23343	Cable	ÖZ-J 3 x 1.0 mm²	4000 mm
48	F20696	Cable	ÖZ-J 12 x 0.5 mm²	7550 mm
49	F23523	Cable	ÖZ-O 2 x 1.0 mm²	3400 mm
50	F29221	Resistance thermometer IR/LR	PT100 DIN EN 60751	1
51	F23523	Cable	ÖZ-O 2 x 1.0 mm²	2500 mm
52	F23523	Cable	ÖZ-O 2 x 1.0 mm²	2500 mm
53	F23523	Cable	ÖZ-O 2 x 1.0 mm²	5100 mm
54	F28388	Contact element 1Ö	E01	1
55	F20700	Cable	Liycy 3 x 0.5 mm²	4700 mm
56	F28100	Cable	Liycy 3 x 0.5 mm²	4850 mm
57	F28100	Cable	Liycy 3 x 0.5 mm²	3650 mm
58	F28100	Cable	Liycy 3 x 0.5 mm²	3650 mm
59	F25303	Cable	ÖZ-J 7x1.0 mm²	5200 mm
60	F25303	Cable	ÖZ-J 7x1.0 mm²	4000 mm
61	F23343	Cable	ÖZ-J 3 x 1.0 mm²	4000 mm
62	F23343	Cable	ÖZ-J 3 x 1.0 mm²	5000 mm
63	F23343	Cable	ÖZ-J 3 x 1.0 mm²	5000 mm
