Pulse Generator Exploded View Ruhle IR56 No. 473 and Higher
Pos No. | Part No. | Description | Add Info | Required | |
1 | F451597 | Traverse | IR 28/56 | 1 | |
2 | F42311 | Lever | IR 28/56 | 1 | |
3 | F440166 | Lever | IR 28/56 | 1 | |
4 | F29300 | Ring | Ø 28,2 x Ø 40 x 4,8 | 2 | |
5 | F29301 | Disc | Ø 12,5 x Ø 40 x 4 | 2 | |
6 | F20179 | Hexagonal nut | DIN439 M 12 | 4 |
