PSS Two-level Mixers

Type: Mixing Capacity: 1102 lbs- 5953 lbs
Country of Origin: Slovakia
Ships from: FOB Brampton, ON Canada (O)
U/M: Each
Stock: On Order
CM: 8450

Note: Shipping to be determined

* Two-Level Mixer Options:

CM Machine Services Ltd. Product Information

To make Purchase Call 905-793-3994 or Email sales@cmmachineservices.net Prices are subject to change without notice.

PSS Two-level Mixers

Type: Mixing Capacity: 1102 lbs- 5953 lbs
Location: FOB Brampton, ON Canada (O)
U/M: Each
Stock: On Order
CM Product Code: 8450

Note: Shipping to be determined

* Two-Level Mixer Options:
--SM 500
--SM 700
--SM 900
--SM 1200
--SM 1700
--SM 2200
--SM 2700

PSS Two-level Mixers

PSS mixers are designed for food industry operations for the fast mixing of any kind of product. PSS mixers ensure even and gentle mixing regardless of product structure.

Parameter	SM 500	SM 700	SM 900	SM 1200	SM 1700	SM 2200	SM 2700
Total hopper volume	650 L	900 L	1,200 L	1,500 L	2,100 L	3,200 L	3,900 L
Net mixing volume	500 L	700 L	900 L	1,200 L	1,700 L	2,200 L	2,700 L
Control via frequency inverters	no	yes	yes	yes	yes	yes	yes
Total input	5,7 kW	8 kW	11,5 kW	15,5 kW	22,5 kW	25 kW	30 kW
Weigh of the machine	900 kg	1,700 kg	1,800 kg	2,100 kg	2,500 kg	3,300 kg	4,600 kg
Dimensions (LxWxH)	2158 mm x 1185 mm x 2100 mm	2420 mm x 1350 mm x 2110 mm	2725 mm x 1350 mm x 2300 mm	2720 mm x 1500 mm x 2430 mm	3170 mm x 1500 mm x 2430 mm	3270 mm x 1800 mm x 2740 mm	3570 mm x 1800 mm x 2740 mm
Voltage network	3/PE/N 50Hz 230/400V TN-C-S	3/PE/N 50Hz 230/400V TN-C-S	3/PE/N 50Hz 230/400V TN-C-S	3/PE/N 50Hz 230/400V TN-C-S	3/PE/N 50Hz 230/400V TN-C-S	3/PE/N 50Hz 230/400V TN-C-S	3/PE/N 50Hz 230/400V TN-C-S
Standardized AC voltage	230/400 V ± 10%	230/400 V ± 10%	230/400 V ± 10%	230/400 V ± 10%	230/400 V ± 10%	230/400 V ± 10%	230/400 V ± 10%
Control voltage	230/24 V AC	230/24 V AC	230/24 V AC	230/24 V AC	230/24 V AC	230/24 V AC	230/24 V AC

CM Machine Services Ltd. | 55 Stafford Drive Unit "I" | Brampton, On L6W 1L3

PH: 905-793-3994 | Contact: sales@cmmachineservices.net

Description Videos

PSS Two-level Mixers

PSS mixers are designed for food industry operations for the fast mixing of any kind of product. PSS mixers ensure even and gentle mixing regardless of product structure.

Parameter	SM 500	SM 700	SM 900	SM 1200	SM 1700	SM 2200	SM 2700
Total hopper volume	650 L	900 L	1,200 L	1,500 L	2,100 L	3,200 L	3,900 L
Net mixing volume	500 L	700 L	900 L	1,200 L	1,700 L	2,200 L	2,700 L
Control via frequency inverters	no	yes	yes	yes	yes	yes	yes
Total input	5,7 kW	8 kW	11,5 kW	15,5 kW	22,5 kW	25 kW	30 kW
Weigh of the machine	900 kg	1,700 kg	1,800 kg	2,100 kg	2,500 kg	3,300 kg	4,600 kg
Dimensions (LxWxH)	2158 mm x 1185 mm x 2100 mm	2420 mm x 1350 mm x 2110 mm	2725 mm x 1350 mm x 2300 mm	2720 mm x 1500 mm x 2430 mm	3170 mm x 1500 mm x 2430 mm	3270 mm x 1800 mm x 2740 mm	3570 mm x 1800 mm x 2740 mm
Voltage network	3/PE/N 50Hz 230/400V TN-C-S	3/PE/N 50Hz 230/400V TN-C-S	3/PE/N 50Hz 230/400V TN-C-S	3/PE/N 50Hz 230/400V TN-C-S	3/PE/N 50Hz 230/400V TN-C-S	3/PE/N 50Hz 230/400V TN-C-S	3/PE/N 50Hz 230/400V TN-C-S
Standardized AC voltage	230/400 V ± 10%	230/400 V ± 10%	230/400 V ± 10%	230/400 V ± 10%	230/400 V ± 10%	230/400 V ± 10%	230/400 V ± 10%
Control voltage	230/24 V AC	230/24 V AC	230/24 V AC	230/24 V AC	230/24 V AC	230/24 V AC	230/24 V AC
