Multi-blade Cutting Cortex MBC 430
Type: belt width:430mm
Country of Origin: Germany
Ships from: FOB Brampton, ON Canada
U/M: Each
Stock: On Order
CM: 6434
Country of Origin: Germany
Ships from: FOB Brampton, ON Canada
U/M: Each
Stock: On Order
CM: 6434
Financing Available
Note: Shipping to be determined
Nock Cortex MBC 430 Multi-blade Cutting Machine
Cutting machine with vertical cutting direction for meat and other products
Features and application range:
- Multi-blade cutter with vertical cutting direction for meat and other products
- Long-stroke and low-frequency oscillating blade frame for a particularly gentle cut
- Conveyorized machine with infeed and discharge conveyor; machine can be fed fully automatic
- Low-noise and low-vibrating operation of the machine
- Hygienic and easy-to-clean
- Easy-to-change blade frame
- Cutting width is 430 mm
- Minimum blade distance depending on product is about 3 mm
Standard equipment:
- Special system for low-keeping and pushing the product
- 1-blade-frame
- Infeed conveyor
- Discharge conveyor
- Safety covers with pneumatic release
- NOCK POWER PLATES® for NOCK-specific robustness and service-friendliness
- Lockable castors
- Stainless steel
|
Technical data Cortex MBC 430 |
|
|
standard throughput height |
40-125mm (optional: 40-180mm) |
|
max. product length |
400mm (optional: longer) |
|
cutting width |
430mm |
|
infeed conveyor speed |
5.5 m /min |
|
min blade distance |
from 3mm |
|
blade frequency |
140 Hz |
|
blade stroke |
150mm |
|
overall dimensions W x H x D |
1120 x 2000 x 2260mm |
|
weight |
690 kg |
|
electrical consumption |
2,0 kW |
|
electrical connection |
Standard 3 AC - 400 V - 50 Hz IEC 60309 16 A 6h other voltages upon request |
|
compressed air connection |
5 < p <10 bar |
|
compressed air consumption |
approx. 50 l/min (ambient pressure) |
