Lever Exploded View SR3 Meat Dicer No. 35 and higher

Type: 1027960
Ships from: FOB Brampton Canada
U/M: Each
Stock: On Order
CM: 1124

Note: Shipping to be Determined.

* Lever Exploded View SR3 Lifting unit No. 35 and higher:

CM Machine Services Ltd. Product Information

To make Purchase Call 905-793-3994 or Email sales@cmmachineservices.net Prices are subject to change without notice.

Lever Exploded View SR3 Meat Dicer No. 35 and higher

Type: 1027960
Location: FOB Brampton Canada
U/M: Each
Stock: On Order
CM Product Code: 1124

Note: Shipping to be Determined.

* Lever Exploded View SR3 Lifting unit No. 35 and higher:
--F22608 Disc
--F41839 Lever
-- F28418 Disc
--F24013 Countersunk bolt
--F20543 Washer
-- F20450 Hexagonal nut

Lever Exploded View SR3 Meat Dicer No. 35 and higher

Pos No.	Part No.	Description	Add Info	Required
1	F22608	Disc	Ø 68,5 x Ø 75 x 6	2
2	F41839	Lever	SR 3	1
3	F28418	Disc	Ø 13 x Ø 75 x 4	1
4	F24013	Countersunk bolt	DIN7991 M12 x 30	1
5	F20543	Washer	DIN125 A 21	1
6	F20450	Hexagonal nut	DIN934 M 20 x 1,5	1

CM Machine Services Ltd. | 55 Stafford Drive Unit "I" | Brampton, On L6W 1L3

PH: 905-793-3994 | Contact: sales@cmmachineservices.net

Description

Lever Exploded View SR3 Meat Dicer No. 35 and higher

Pos No.	Part No.	Description	Add Info	Required
1	F22608	Disc	Ø 68,5 x Ø 75 x 6	2
2	F41839	Lever	SR 3	1
3	F28418	Disc	Ø 13 x Ø 75 x 4	1
4	F24013	Countersunk bolt	DIN7991 M12 x 30	1
5	F20543	Washer	DIN125 A 21	1
6	F20450	Hexagonal nut	DIN934 M 20 x 1,5	1
