Knife Shaft Exploded View

Type: F41616ex
Ships from: FOB Brampton Canada
U/M: Each
Stock: On Order
CM: 730

Note: Shipping to be Determined.

* Knife Shaft Exploded View SR2-Turbo No. 74 and higher:

CM Machine Services Ltd. Product Information

To make Purchase Call 905-793-3994 or Email sales@cmmachineservices.net Prices are subject to change without notice.

Knife Shaft Exploded View

Type: F41616ex
Location: FOB Brampton Canada
U/M: Each
Stock: On Order
CM Product Code: 730

Note: Shipping to be Determined.

* Knife Shaft Exploded View SR2-Turbo No. 74 and higher:
--F26814 Take-up ring
--F28057 Radial shaft seal
--F26809 Housing
--F23386 Schrägkugellager
--F26811 Ring
--F26813 Scheibe
--F26812 Knife shaft
--F21380 Disc
--F26817 Double chain wheel
--F21393 Disc
--F26897 Hexagonal nut
--F26819 Nut
--F27129 Nut

Part No.	Description	Add. Info	Required
1	F26814	Take-up ring	Ø 50 x Ø 72 x 20
2	F28057	Radial shaft seal	Ø 50 x Ø 65 x 8
3	F26809	Housing	Ø 120 x 111,5
4	F23386	Schrägkugellager	DIN628 - 3207 2RS
5	F26811	Ring	Ø 35,5 x Ø 45 x 40,5
6	F26813	Scheibe	Ø 55 x Ø 71 x 2
7	F26812	Knife shaft	Ø 50 x 264
8	F21380	Disc	Ø 35,5 x Ø 45 x 5
9	F26817	Double chain wheel	Z 20-1/2x5/16
10	F21393	Disc	Ø 20,5 x Ø 45 x 2,5
11	F26897	Hexagonal nut	DIN439 M 20 x 1,5
12	F26819	Nut	M 40 x 1,5 x Ø 50 x 11
13	F27129	Nut	M 40 x 1,5 x Ø 50 x 11
