Drive Shaft Exploded View for Meat Injector
Pos No. | Part No. | Description | Add Info | Required | |
1 | F42332 | Flange | IR 56 | 2 | |
2 | F445629 | Drive Shaft | IR 56 | 2 | |
3 | F240924 | Shaft | Ø 20 x 147 | 6 | |
4 | F29339 | Support | 424 x 44 x 5 | 1 | |
5 | F240926 | Plate / Sheet | 122,5 x 97,3 x 3 | 2 | |
6 | F101049 | bearing | IR 56 | 2 | |
7 | F27693 | Washer | DIN125 A 10,5 | 6 | |
8 | F20147 | Hexagonal nut | DIN934 M 10 | 6 |
