Drive Shaft Exploded View 2 Ruhle IR56 Injector F42284

Type: F42284
Ships from: FOB Brampton Canada
U/M: Each
Stock: On Order
CM: 2379

* Drive Shaft Exploded View 2 IR 56 No. 210 and higher:

CM Machine Services Ltd. Product Information

To make Purchase Call 905-793-3994 or Email sales@cmmachineservices.net Prices are subject to change without notice.

Drive Shaft Exploded View 2 Ruhle IR56 Injector F42284

Type: F42284
Location: FOB Brampton Canada
U/M: Each
Stock: On Order
CM Product Code: 2379

* Drive Shaft Exploded View 2 IR 56 No. 210 and higher:
--F441845 Drive shaft
--F29341 Rolle
--F440337 Lever
--F22916 Washer
--F26133 Hexagonal nut
--F20202 Washer
--F20179 Hexagonal nut
--F244906 compensating disc
--F248683 compensating disc
--F21907 Ring
--F20837 Threaded pin

Drive Shaft Exploded View 2 Ruhle IR56 Injector F42284

Pos No.	Part No.	Description	Add Info	Required
1	F441845	Drive shaft	IR 28/56	1
2	F29341	Rolle	Ø 50 x 45	2
3	F440337	Lever	IR 28/56	1
4	F22916	Washer	DIN125 A 15	1
5	F26133	Hexagonal nut	DIN439 M 14	1
6	F20202	Washer	DIN125 A 13	2
7	F20179	Hexagonal nut	DIN439 M 12	2
8	F244906	compensating disc	Ø 20,3 x Ø 39 x 1,5	1
9	F248683	compensating disc	Ø 20,3 x Ø 39 x 0,65	1
10	F21907	Ring	Ø 20,1 x Ø 40 x 12	1
11	F20837	Threaded pin	DIN914 M 8 x 10	1
